Технические характеристики

Frequency Response (+/-3 dB)

50 Hz - 16 kHz (System), 210 Hz - 16 kHz (Satellites)

Long-Term Power Handling

System: 70/100 V: 200 W (800 W peak), System Low impedance: 100 W (400 W peak), Satellites: 12W (48W Peak)

Maximum SPL @ 1 m

System: 93 dB (99 dB SPL peak in a 45,000 ft³ room, with RT60 of 1 second, +/- 3 dB), Satellites : 95 dB (101 dB SPL peak)

Frequency Range (-10 dB

40 Hz - 20 kHz (System), 170 Hz - 20 kH z (Satellites)

Sensitivity (SPL / 1 W @ 1 m)

82 dB SPL (System), 84 dB SPL (Satellites)

Nominal Impedance

 4-Cube System: 6 Ω per channel, 2-Cube System: 5 Ω per channel (surface);, 6 Ω per channel (flush)

Чертежи
